LSQ15RP

Swimming Pool Heat Pump With a highly efficient SIRAC heat pump you can enjoy your swimming pool and spa all year round. They are affordable, reliable and their high efficiency keeps your electricity bill to a minimum.

Key Features
one of the quietest and most efficient units in the industry
exceptionally good value without compromise on quality or performance
rated for ambient conditions between - 15℃ and + 45℃
compact, easy to install plug in system
titanium heat exchanger for resistance against corrosion and pool chemicals
fully automatic control with adjustable water temperature setting
suitable for retrofits and new installations
low maintenance

Features：
1. Data rated in ambient air of 27℃ and entering water of 27℃.
2. Corrosion resistant Titanium heat exchanger.
3. Stainless Steel Cabinet optional.
4. LCD display controller.
5. Automatic unit on/off timer clock.
6. Insufficient water flow protection.
7. High/Low pressure protection.
8. Automatic reversing defrosting function enables units to work reliably in chilling climates.
9. Cool water function optional.

Model No.     LSQ025RP
Standard Outlet Temperature:    27°C
Maximum Outlet Temperature:   60°C
Heating Capacity(A20℃):                        10KW
Power Input(A20℃):                  1.9KW
Heating Capacity(A20℃):                        8KW
Power Input(A20℃):                  1.8KW
Power connection:    220V/1Ph/50Hz
Rated Running Current:    9A
Type/ Brand of compressors:   Rotary
No. of Compressor:    One
No. of Fan Motor:    One
Gas Flow Restriction:    4-way Reversing Valve
Type of Condenser:    Titanium
Refrigerant:     R407C
Quantity of refrigerant:   1.3Kg
Connection for inlet and outlet (inch):  2”
Air Discharge Direction:   Horizontal
Noise Da(B):                                    51
Dimension:     1200mm (L) x 560mm (W)x 610 (H)
Net weight:     90kg
